Wāvtech link700.4plus

The link700.4plus is the most versatile 4-channel amplifier available. Like our mini series multi-channel amplifiers, the plus series models have built-in summing. But with the additional width, we can now accommodate 6-channels of input. That means you can sum a 3-way OEM system and get front and rear full-range output, plus an RCA Pre-Out for a subwoofer amplifier. It is powerful, producing 100 watts x 4 RMS @ 4 ohms, or 175 watts RMS x 4 @ 2 ohms. In BTL mode the power is 350 watts x 2 RMS @ 4 ohms.

The link700.4plus has our bassFREQ processor, with 24 dB/octave lowpass and subsonic filters, as well as a fully adjustable 1-band parametric EQ. The optional RLC can be configured to control channels 3/4 when in lowpass mode, or the RCA Pre-Out.

link700.4plus Features

• 700 Watt 4-Channel Amplifier

• 100 watts x 4 @ 4 ohms

• 175 watts x 4 @ 2 ohms

• 350 watts x 2 @ 4 ohms BTL

  • Small Footprint Only 10.25”x5.5”x1.65”

  • Variable HP Crossover (-12dB/oct) with 1x/10x CH1/2

  • Variable HP/BP/LP Crossover (-12dB/oct) CH3/4

  • Variable LP Crossover (-24dB/oct) RCA Pre-Out

  • Variable Subsonic Filter (-24dB/oct) RCA Pre-Out

  • Adjustable Parametric EQ RCA Pre-Out

• Remote Level Control (RLC) w/Optional linkRC (Channels 3/4 or RCA Pre-Out)

• Built-In Summing w/Level Trim Adjsutment

• Start/Stop Sytem Compatiable

• Differential Balanced Inputs

• Variable Gain Adjustment w/Clip LED

• Auto Turn-On via DC-Offset or Audio Signal Detect

• Adaptive OEM Load Technology

• Locking Detachable Hi-Level Speaker Terminals

• Professional Grade Panel Mount RCA’s

• Compact Aluminum Chassis w/Detachable Mounting tabs
